Laurel’s bio soluble ceramic fiber blanket is a next-generation insulation material designed for extreme thermal environments where both performance and sustainability are critical. This bio soluble fiber blanket is manufactured from advanced, biodegradable ceramic fibers engineered to dissolve naturally in biological environments—dramatically reducing health hazards and long-term environmental impact.

As a bio soluble insulating blanket, it offers superior thermal resistance, flexibility, and strength while being non-toxic, halogen-free, and fully recyclable. Its lightweight structure and easy installation make it suitable for a wide range of high-temperature industrial applications, especially where compliance with global eco-safety standards is required.


Product Details

Application

Metallurgy & Foundry Applications

The bio soluble ceramic fiber blanket is used to line induction furnaces, ladles, and molten metal equipment—offering high-temperature insulation with safer handling compared to traditional fibers.

Petrochemical & Refining Systems

This bio soluble insulating blanket is ideal for pipe wrapping, vessel insulation, and flange protection in high-temperature and chemically aggressive settings.

Energy & Power Generation

As a bio soluble fiber blanket, it provides effective thermal protection in boilers, turbines, and HRSG systems, significantly reducing heat loss and enhancing energy efficiency.

Automotive & EV Components

Used as a bio soluble ceramic fiber blanket fire barrier in EV battery compartments, exhaust system insulation, and noise-reducing layers in automotive interiors.

Marine & Aerospace Insulation

Its lightweight and vibration-resistant nature makes the bio soluble insulating blanket ideal for insulating ship engine rooms and aerospace ducting exposed to rapid heat fluctuations.

Green Building & Passive Fireproofing

Integrated into ceilings, walls, and doors, the bio soluble fiber blanket serves as a passive fireproofing solution in eco-certified commercial and residential buildings.


Table parameters

Item

1100℃ Bio-soluble Fiber Blanket

Density (kg/m3)

64

96

128

Permanent Linear Shrinkage(%)

1100℃×24h≤1.0

Tensile Strength(Mpa)

0.03

0.05

0.07

Shot Content(%)

≤12

Thermal Conductivity (W/m.k)

400℃

0.10

0.09

0.08

600℃

0.16

0.13

0.12

800℃

0.27

0.20

0.17

Chemical Composition(%)


SiO2(%)

61-67

CaO(%)

27-33

MgO(%)

4-7


Features

Features

Features of Bio Soluble Ceramic Fiber Blanket

100% bio soluble fiber blanket, biodegradable and eco-compliant

Excellent insulation in temperatures up to 1200°C

Bio soluble insulating blanket with high thermal shock resistance

Lightweight, strong tensile integrity, and low heat conductivity

Free of toxic binders or halogen-based chemicals

Easy to cut, install, and layer for custom applications

Certified under ISO, ASTM, and EU environmental safety regulations
