Ceramic Fiber Resistant Insulation Board For Sale

$High Temperature Refractory Ceramic Fiber Insulation Board$

$High Temperature Refractory Ceramic Fiber Insulation Board$

Fire Resistant Board

Laurel Ceramic Fiber Board is a robust and versatile insulation solution designed to perform under extreme heat conditions. Produced from high-purity ceramic fiber materials and precision-formed into rigid panels, it offers a unique balance of thermal protection, structural integrity, and design flexibility. Capable of withstanding continuous exposure to temperatures ranging from 1230°C to 1430°C, the board excels in thermal control, shock resistance, and dimensional stability. It is an ideal solution for demanding high-temperature processes, offering superior insulation for everything from industrial kilns to petrochemical reactors.Laure professional ceramic fiber board for sale, providing you with quality service and high quality products.

Inquiry Now

Product Details
Table Parameters
Features
Applications
Related Products
Inquiry Now

Product Details

Applications of Fire Resistant Insulation Board

Iron & Steel Industry: Skid rails, ladle covers, reheat furnace linings.

Glass Furnaces: Back-up insulation behind hot face layers, crown insulation.

Non-Ferrous Metals: Crucible insulation and smelting furnace wall protection.

Chemical & Petrochemical Plants: Insulation for reactors, cracking units, and high-temperature ducts.

Ceramic Manufacturing: Kiln car insulation, wall lining, and firing chamber panels.

Power Generation: Lining for boiler walls, turbine housings, and flue systems.

Backed by decades of refractory innovation, Laurel Ceramic Fiber Board brings together safety, performance, and flexibility in one rigid solution. Whether you need Ceramic Fire Board, backup insulation, or specialty furnace linings, we provide tailored products that meet global industrial standards. Choose Laurel for reliable, safe, and versatile solutions.

Table parameters

Item	STD BOARD	HP BOARD	HA BOARD	HZ BOARD
Classification Temperature (ºC)	1260	1260	1350	1430
Loss of Ignition(%)	≤6	≤6	≤6	≤6
Density (kg/m3)	250-350	250-350	250-350	250-350
Permanent Linear Shrinkage(%)(24 hours)	≤3(1000°C)	≤3(1100°C)	≤3.5(1200°C)	≤3.5(1350°C)
Compressive Strength (Mpa)	0.15-0.3	0.15-0.3	0.15-0.3	0.15-0.3
Thermal Conductivity(W/m·k)
400 ºC	0.09	0.07	0.07	0.07
800 ºC	0.15	0.14	0.13	0.13
1000 ºC	0.2	0.2	0.2	0.19

Features

Features of Ceramic Fire Board

Operating Temperature: 1230°C – 1430°C

Density Range: 280 – 450 kg/m³

Standard Thickness: 6mm – 50mm

Key Functions: Refractory lining / Thermal insulation / Passive fire protection

Form Factor: Rigid, pre-cut board – easily trimmed or machined to fit application requirements.

High Compressive Strength: Maintains rigid thermal performance.

Low Thermal Conductivity and Heat Storage Capacity: Minimizes heat loss.

Fast Installation: Minimal dust release during cutting.

Thermal Shock and Chemical Resistance: Suitable for aggressive operating environments.

Lightweight Structure: Easier transport and on-site assembly.

Fully Recyclable: Free from asbestos or carcinogenic compounds.

Applications

Steel Industry

Aluminum Industry

Cement Industry

Glass Industry

Ceramic Industry

Foundry Industry

Petrochemical Industry

Power Industry

Energy and environmental protection

Other metallurgical industries

Building Insulation Materials

Pizza oven
