Fused Zirconia Corundum Bricks

Laurel’s zircon corundum refractory brick series—also known as fused zirconia corundum bricks or AZS bricks (Alumina-Zirconia-Silica)—are high-purity electro-cast refractories designed for use in the most corrosive and thermally demanding glass furnace environments. These electro-fused zircon corundum bricks for sale are produced by melting premium-grade raw materials in electric arc furnaces and casting them into precision-controlled molds.

Whether you're sourcing fused zirconia corundum bricks, custom-shaped zircon corundum refractory brick, or premium electro-fused zircon corundum bricks for sale, Laurel delivers reliable solutions for the harshest conditions in glass manufacturing.


Product Details


Applications

Throat and doghouse sections of float glass furnaces

Sidewalls and paving zones in melting tanks

Feeder systems, including working ends and spouts

High-purity and specialty glass production (e.g., LCD, borosilicate, aluminosilicate)


Table parameters

Item

Specification


AZS33Y

AZS36Y

AZS41Y

ZrO2  %

32~36

35~40

40~44

SiO2  %

≤16

≤14

≤13

Na2O  %

≤1.45

≤1.45

≤1.3

Fe2O3+TiO2+CaO+MgO+K2O+Na2O  %

≤2.0

≤2.0

≤2.0

Fe2O3+TiO2  %

≤0.3

≤0.3

≤0.3

Bulk Density, g/cm3

≥3.75

≥3.8

≥3.95

Apparent Porosity, %

≤1.5

≤1.0

≤1.0

Static Corrosion, 1500℃×36h  mm/24h

≤1.6

≤1.5

≤1.3

Exudation Temperature, ℃

≥1400

≥1400

≥1400

Bubble Precipitation Rate, 1300℃×10h  %

≤2.0

≤1.5

≤1.0

Exudation Amount of Glass Phase, 1500℃×4h  %

≤2.0

≤3.0

≤3.0

Bulk Density, kg/m3

Unit Weight>50Kg

PT/QX

≥3400

≥3450

≥3550


ZWS

≥3600

≥3700

≥3850


WS

≥3700

≥3750

≥3900


Features

Features

Outstanding Resistance to Molten Glass Corrosion

The eutectic structure formed in fused zirconia corundum bricks offers exceptional resistance to molten glass attack, effectively reducing penetration and dissolution over prolonged contact cycles.

Long-Term Stability in Alkaline Vapor Zones

Each zircon corundum refractory brick features a dense, glass-phase-free composition that resists sodium vapor and alkaline infiltration—minimizing stone defects, blistering, and unwanted reactions during float or borosilicate glass production.

Thermal Durability Above 1800°C

These electro-fused zircon corundum bricks are thermally stable and dimensionally precise, even under constant high-temperature operation. Ideal for structural zones exposed to both heat and mechanical load.

Ultra-Low Porosity and Impurity Control

Thanks to controlled fusion and casting, fused zirconia corundum bricks achieve porosity ≤1.0%, drastically limiting glass contamination and ensuring exceptional clarity in end-product quality.
