Ceramic Insulation Paper​

Laurel Ceramic Fiber Paper is a next-generation refractory insulation material crafted from premium alumina-silicate fibers. Engineered through advanced fiber forming technology, it offers a uniform, low-density structure with exceptional thermal stability, flexibility, and fire resistance. Designed to meet the demands of modern industrial processes, this paper excels in environments where both high-temperature performance and dimensional precision are critical.

Available in convenient Ceramic Fiber Paper Roll and Ceramic Fiber Insulation Roll formats, Laurel Ceramic Fiber Paper is ideal for use in thermal gaskets, expansion joints, battery insulation, and flame barriers. Compatible with temperatures up to 1200°C, it delivers consistent protection and energy efficiency across industries such as automotive, metallurgy, electronics, power generation, and aerospace.


Product Details


Applications of Ceramic Fiber Paper Roll

Power & Energy: Insulating transformers, boilers, and exhaust flanges.

Electronics & EVs: Battery compartment barriers, PCB thermal pads.

Metal Casting & Forging: Lining for molds, crucibles, and ladle covers.

Automotive: Tailpipe and muffler wrapping, shielding for engine bays.

Aerospace & Defense: High-temp sealing for turbines and avionics.

Glass & Ceramics: Kiln insulation and flame barriers for precision forming.

As a top Ceramic Fiber Insulation Roll supplier, Laurel offers high-quality, reliable solutions.Backed by decades of experience in refractory solutions, Laurel’s Ceramic Insulation Paper provides the perfect blend of performance, reliability, and customization. Choose Laurel for your industrial insulation needs.


Table parameters

ItemSTD PAPERHA PAPERHZ PAPER
Classification Temperature(ºC)126013501450
Working Temperature(ºC)110012001350
ColorWhiteWhitePure White
Density(kg/m3)180-220180-220180-220
Thermal Conductivity(W/m·k)0.08(400ºC)0.08(400ºC)0.08(400ºC)
0.12(600ºC)0.13(600ºC)0.13(600ºC)
0.20(800ºC)0.19(800ºC)0.18(800ºC)
Tensile Strength(Mpa)0.40.70.7
Chemical CompositionAl2O3(%)42-4545-5035-38

SiO2(%)54-5749-5444-49

ZrO2(%)--15-17


Features

Features of Ceramic Insulation Paper

Service Temperature: Continuous use up to 1200°C

Density: 180–220 kg/m³

Thickness Options: 1–10 mm (tailored options available)

Thin Profile with Excellent Insulating Capacity: Provides superior thermal protection.

Resistant to Thermal Shock and Mechanical Stress: Ensures long-term durability.

Smooth, Consistent Surface Texture: Ensures reliable performance.

Electrically Non-Conductive: Suitable for electronic insulation.

Resilient Against Corrosion and Most Acids/Alkalis: Ensures chemical stability.

Easy to Cut, Laminate, and Install: Offers outstanding workability.
